The Schöck Isokorb® T type SQ is a load bearing thermal insulation element with 80 mm insulation thickness for connecting supported steel girders to a reinforced concrete slab. The Schöck Isokorb® T type SQ makes it easy to solve the technical and structural issues of designing modern balconies and façades.

Schöck Isokorb® T type SQ: Thermal insulation element for supported steel balconies

BBA Certification
Technically approved and certified by the BBA
Independently verified
A thermal modelling study was undertaken by the OISD (Oxford Brookes University)
Detailed planning literature
Technical Information, Certificates, Approvals, the Thermal Bridging Portal and Installation instructions
Construction dependability
Cantilevered steel structures such as steel balconies with no risk of condensation, mould or corrosion
Broad range of applications
E.g. for steel balconies, steel canopy roofs, façade substructures or shade systems
Installation jig
For fast and accurate installation

Technical Information

Technical Information Schöck Isokorb® T type SQ

pdf, 787,95 KB

(01/06/2022)

read now

download now

Installation instructions

Installation Instruction Schöck Isokorb® T type SQ

pdf, 1,77 MB

(13/06/2023)

read now

download now

All Downloads Schöck Isokorb® T type SQ
